Dali Dimming LED Driver DT8

Name: Dali Dimming LED Driver DT8
Brand: SARLUX ELECTRONICS
Price: 1190.0 INR
Availability: InStock

Price 1190.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece Piece

Dali Dimming LED Driver DT8 Specification

Housing
Non-flammable PC

Current Rating
4A max per channel

Operating Temperature
-20 C to +50 C

Light Color
Tunable White

Power Supply
AC Mains

Response Time
<200 ms

Shape
Rectangular

Life Span
>50,000 hours

Humidity %
20% - 90% RH (non-condensing)

Control Type
DALI DT8 (Tunable White)

Efficiency (%)
>88%

Product Type
DALI Dimming LED Driver DT8

Material
Polycarbonate housing

Base
Screw terminal

Power Factor
>0.9

Input Voltage
220-240V AC, 50/60Hz

Working Temperature
-20 C to +50 C

Lamp Power
2 x 75W

Application
Commercial Lighting, Office, Smart Home

Dimension (L*W*H)
13*2*3.5 Centimeter (cm)

Weight
200g

Color
white

LED Type
Constant Voltage

Color Temperature
Tunable White (DT8) 2700K-6500K

IP Rating
IP20

THD (Total Harmonic Distortion)
<15%

Output Channels
2 channels (for Tunable White/CCT control)

Dimming Range
1% - 100%

Mounting Type
Surface or recessed mount

DALI Protocol
DALI-2 DT8 compliant

Surge Protection
4kV

Isolation
SELV (Safety Extra Low Voltage)

Dali Dimming LED Driver DT8 Trade Information

Minimum Order Quantity
1 Piece Piece

Delivery Time
1 Week

About Dali Dimming LED Driver DT8

DALI | Flicker-Free | Dimmable | Constant Current
High performance DALI dimming LED driver with constant current output, flicker-free operation and wide compatibility. Ideal for indoor LED lighting applications.

Advanced Tunable White Control

Experience exceptional lighting flexibility with precise CCT and intensity adjustment using two channels for seamless Tunable White control. Adapt color temperatures from a warm 2700K to a crisp 6500K to suit various room environments and personal preferences, ensuring both comfort and productivity in any application.

Reliable and Efficient Operation

The driver features excellent energy efficiency at over 88%, robust surge protection (4kV), and an advanced low-THD design (<15%). Its safety-focused architecture includes SELV isolation and a flame-retardant polycarbonate housing, supporting reliable performance even in demanding commercial settings.

Versatile Mounting and Application

Designed for both surface and recessed mounting, this compact LED driver easily integrates into office layouts, commercial lighting projects, and smart home systems. The rectangular module fits varied installations, supported by an IP20 rating for dry, indoor spaces.

FAQ's of Dali Dimming LED Driver DT8:

Q: How do I control the color temperature using the Dali Dimming LED Driver DT8?

A: The driver supports DALI-2 DT8 protocol, enabling seamless control of color temperature (CCT) through two output channels. Using a compatible DALI DT8 controller, you can easily adjust the light from warm (2700K) to cool white (6500K), providing a tunable white effect tailored to your project's requirements.

Q: What type of LED lights are supported by this driver?

A: This driver is designed for constant voltage LED fixtures requiring tunable white capabilities. It supports up to two channels, each with a 4A maximum current, and a total lamp output of up to 2 x 75W, making it suitable for a wide range of commercial and residential lighting setups.

Q: Where can I install the Dali Dimming LED Driver DT8?

A: The unit is suitable for indoor use in commercial offices, smart homes, and retail environments. Its versatile design allows for both surface and recessed mounting, adapting to a variety of installation scenarios. The IP20 rating ensures it is protected against solid objects and suitable for dry, indoor locations.

Q: What are the safety and reliability features of this LED driver?

A: This LED driver boasts SELV (Safety Extra Low Voltage) isolation to protect against electrical hazards, a robust 4kV surge protection, and a polycarbonate, non-flammable housing. Additionally, it operates efficiently with a power factor above 0.9 and a lifespan exceeding 50,000 hours.

Q: How does the dimming process work with this driver?

A: The Dali Dimming LED Driver DT8 enables precise dimming from 1% up to 100% using a DALI-compatible controller. Thanks to its rapid response time (<200 ms) and low total harmonic distortion (<15%), users experience smooth, flicker-free transitions and consistent illumination quality.

Q: What benefits does the DT8 driver offer compared to standard dimming LED drivers?

A: The key advantage lies in its dual-channel tunable white control, DALI-2 DT8 protocol support, high efficiency, robust surge protection, and flexible installation options. It provides both improved lighting quality and energy savings, ensuring a future-proof solution for demanding lighting environments.
